特點Features

●適用于各種局部凈化設(shè)備和潔凈廠房的末端凈化

●Applicable to various local purification equipment and clean workshop end purification

Materials and operating conditions

●External frane：Galvanized the casing outside the box or aluminum alloy

●Sealant：Gel-glue

●Filter media：JiaoBanZhi

●Gasket：EVA

●Filter media：Glass fiber

●Use the highest temperature, humidity：80℃、80%

Standard specification

型號 model	外形尺寸 Outside dimensions (mm)	額定風量 Rated air flow (m3/h)	初阻力 Imitial resistance (Pa)	效率（比色法） Efficiency (%)	容塵量 Dust capacity (g)
CJ-H3-K1	305×305×150	250	≤220	≥99.99	200
CJ-H3-K2	320×320×220	400	≤220	≥99.99	350
CJ-H3-K3	484×484×150	600	≤220	≥99.99	400
CJ-H3-K4	484×484×220	1000	≤220	≥99.99	600
CJ-H3-K5	726×484×220	1500	≤220	≥99.99	900
CJ-H3-K6	968×484×220	2000	≤220	≥99.99	1200
CJ-H3-K7	610×610×150	1000	≤220	≥99.99	600
CJ-H3-K8	915×610×150	1500	≤220	≥99.99	900
CJ-H3-K9	1220×610×150	2000	≤220	≥99.99	1200
CJ-H3-K10	630×630×220	1600	≤220	≥99.99	900
CJ-H3-K11	945×630×220	2400	≤220	≥99.99	1400
CJ-H3-K12	1260×630×220	3200	≤220	≥99.99	1800
